FRENCH SOCKET PDU · VERTICAL · CIRCUIT BREAKER
8-Way French Socket Rack PDU – Vertical with Circuit Breaker
8 way French socket rack PDU for B2B rack and cabinet projects. The 8-Way French Socket Rack PDU is a vertical rack power distribution unit built around eight French/UPS-type outlets and integrated circuit-breaker protection. The archived UPCOM product reference is UP-FR-PDU-CB-1U-8P-VL, where the model coding distinguishes the French socket family, breaker configuration and vertical layout.
Product code: UP-FR-PDU-CB-1U-8P-VL
Product Overview
This is useful for export and cabinet projects where the socket geometry must match French-style equipment connections rather than Schuko, UK or IEC C13. Keeping this model on its own page also makes the exact socket/protection combination directly searchable instead of hiding it inside a general PDU catalogue.
Rack PDU range · Rack cabinets · 19-inch rack cabinet guide · Rack PDU socket types guide · Contact UPCOM
Technical Specifications
The table below contains only model attributes supported by the archived UPCOM model designation and datasheet naming. It intentionally avoids filling missing electrical values with assumptions.
| Product code | UP-FR-PDU-CB-1U-8P-VL |
|---|---|
| Socket standard | French / UPS type |
| Outlet quantity | 8 |
| Orientation | Vertical |
| Protection | Circuit breaker |
| PDU family | Regional-socket protected PDU |
PDU Family Construction Platform
UPCOM’s broader PDU family is designed around rack integration and project customization. Family-level construction options documented in the UPCOM PDU catalogue include aluminum housings, brass socket contacts, fire-retardant plastic components, alternative mounting-ear designs, branding options and multiple socket/protection combinations. These are family capabilities; the final configuration for UP-FR-PDU-CB-1U-8P-VL should be confirmed in the quotation and approved technical document.
When to Choose This PDU
Select this model when the cabinet electrical plan requires French-style outlets, eight connection points and an integrated breaker. For other regional plug standards, use the Rack PDU category to compare Schuko, UK and IEC C13 families before the RFQ is frozen.
For RFQs, confirm socket standard, outlet quantity, mounting direction, required protection or metering, input plug, cable length and destination-country requirements before production.
Applications
- French-market telecom cabinets
- Network and equipment racks using French plugs
- OEM cabinet projects for regional electrical standards
- Export projects requiring breaker-protected rack distribution
This product is intended as a rack-integrated PDU rather than a consumer extension strip. For cabinet sizing and rack-space planning, use the 19-inch rack cabinet guide together with the project drawing.
FAQ
The archived UPCOM material identifies this SKU as the French-type / UPS socket family.
Yes. The VL model designation identifies the vertical configuration.
Yes. CB is part of the model designation and the archived datasheet filename.
Yes. The archived UPCOM PDU range includes multiple French-socket configurations with different outlet counts and protection arrangements.
Specify UP-FR-PDU-CB-1U-8P-VL for Your Project
Send quantity, destination country, cabinet type and electrical requirements. UPCOM can then confirm the applicable PDU configuration and quotation.
