PROTECTED PDU · 12 × C13 · 16A
12-Outlet C13 Protected PDU – Ammeter, Surge & Breaker
12 outlet C13 protected PDU for B2B rack and cabinet projects. The 12-Outlet C13 Protected PDU combines twelve IEC C13 outlets with a 16A model designation, ammeter indication, surge-protection notation and circuit-breaker protection. UPCOM identifies this higher-function configuration as UP-PRT-PDU-1U-12XC13-16A-CB-VL.
Product code: UP-PRT-PDU-1U-12XC13-16A-CB-VL
Product Overview
This SKU belongs to the protected PDU branch rather than the basic outlet-strip family. The archived datasheet filename explicitly carries the AMPERMETER, SP and CB designations, making it suitable for projects that want local current visibility plus additional protection functions at rack level.
Rack PDU range · Rack cabinets · 19-inch rack cabinet guide · Rack PDU socket types guide · Contact UPCOM
Technical Specifications
The table below contains only model attributes supported by the archived UPCOM model designation and datasheet naming. It intentionally avoids filling missing electrical values with assumptions.
| Product code | UP-PRT-PDU-1U-12XC13-16A-CB-VL |
|---|---|
| Socket standard | IEC C13 |
| Outlet quantity | 12 |
| Current designation | 16A |
| Orientation | Vertical |
| Metering | Ammeter |
| Protection | Surge protection + circuit breaker |
| PDU family | Protected rack PDU |
PDU Family Construction Platform
UPCOM’s broader PDU family is designed around rack integration and project customization. Family-level construction options documented in the UPCOM PDU catalogue include aluminum housings, brass socket contacts, fire-retardant plastic components, alternative mounting-ear designs, branding options and multiple socket/protection combinations. These are family capabilities; the final configuration for UP-PRT-PDU-1U-12XC13-16A-CB-VL should be confirmed in the quotation and approved technical document.
When to Choose This PDU
Choose this configuration when a simple C13 outlet strip is not enough and the project requires a more explicit protection and monitoring layer. It is the stronger candidate when local current indication, surge-protection designation and breaker protection are specified together.
For RFQs, confirm socket standard, outlet quantity, mounting direction, required protection or metering, input plug, cable length and destination-country requirements before production.
Applications
- Data and network racks needing local current visibility
- Protected cabinet power distribution
- Integration projects with IEC C13 equipment
- RFQs requiring breaker and surge-protection functions in one PDU
This product is intended as a rack-integrated PDU rather than a consumer extension strip. For cabinet sizing and rack-space planning, use the 19-inch rack cabinet guide together with the project drawing.
FAQ
The archived model and PDF naming include ammeter, surge-protection (SP) and circuit-breaker (CB) designations.
Twelve IEC C13 outlets are identified in the model designation.
Yes. 16A appears directly in the UPCOM model code.
No. This protected model adds metering and surge-protection designations beyond the basic breaker-only C13 configuration.
Specify UP-PRT-PDU-1U-12XC13-16A-CB-VL for Your Project
Send quantity, destination country, cabinet type and electrical requirements. UPCOM can then confirm the applicable PDU configuration and quotation.
