METERED PDU · 12 × IEC C13 · AMMETER
12-Way IEC C13 Metered Rack PDU with Ammeter
12 way C13 metered rack PDU for B2B rack and cabinet projects. The 12-Way IEC C13 Metered Rack PDU combines twelve C13 outlets with local ammeter indication for rack-level power distribution. UPCOM identifies this model as UP-MTR-PDU-1U-12P-C13, separating it from basic C13 breaker models and from the higher-function protected PDU branch.
Product code: UP-MTR-PDU-1U-12P-C13
Product Overview
This SKU is relevant where IEC C13 is the established equipment connection and project teams want a direct current reading without moving into a more complex monitored or intelligent PDU architecture. The dedicated page targets that exact technical buying intent.
Rack PDU range · Rack cabinets · 19-inch rack cabinet guide · Rack PDU socket types guide · Contact UPCOM
Technical Specifications
The table below contains only model attributes supported by the archived UPCOM model designation and datasheet naming. It intentionally avoids filling missing electrical values with assumptions.
| Product code | UP-MTR-PDU-1U-12P-C13 |
|---|---|
| Socket standard | IEC C13 |
| Outlet quantity | 12 |
| Metering | Ammeter |
| Series designation | 1U |
| PDU family | Metered IEC C13 rack PDU |
PDU Family Construction Platform
UPCOM’s broader PDU family is designed around rack integration and project customization. Family-level construction options documented in the UPCOM PDU catalogue include aluminum housings, brass socket contacts, fire-retardant plastic components, alternative mounting-ear designs, branding options and multiple socket/protection combinations. These are family capabilities; the final configuration for UP-MTR-PDU-1U-12P-C13 should be confirmed in the quotation and approved technical document.
When to Choose This PDU
Specify this model when twelve IEC C13 outlets and local current indication are required. If the project additionally calls for surge-protection and breaker functions together, compare the protected 12-outlet C13 PDU rather than treating these two SKUs as interchangeable.
For RFQs, confirm socket standard, outlet quantity, mounting direction, required protection or metering, input plug, cable length and destination-country requirements before production.
Applications
- Server and network racks using C13 power cords
- Integration cabinets requiring current indication
- Telecom racks with IEC-connected equipment
- B2B projects needing a metered but non-intelligent PDU
This product is intended as a rack-integrated PDU rather than a consumer extension strip. For cabinet sizing and rack-space planning, use the 19-inch rack cabinet guide together with the project drawing.
FAQ
Twelve. The archived model and datasheet naming specify 12P / 12xC13.
Yes. The archived datasheet identifies this model as an ammeter-equipped PDU.
The archived source supports local ammeter metering; it does not establish remote network monitoring for this SKU.
The protected C13 model carries additional surge-protection and circuit-breaker designations. This page covers the metered C13 configuration.
Specify UP-MTR-PDU-1U-12P-C13 for Your Project
Send quantity, destination country, cabinet type and electrical requirements. UPCOM can then confirm the applicable PDU configuration and quotation.
